Xerafy

Xerafy Tool Tracking Sample Pack

SKU:
XFY-TOOL-TRACK-PACK-US
$39

Description

Xerafy Tool Tracking Sample Pack

The Xerafy Tool Tracking Sample Pack contains 3 unique RFID tags ideally suited for tool tracking applications: Xerafy Pico-On Plus, Xerafy Dash-On XS, and Xerafy Slim Trak. Offering the ability to test multiple tool tracking tags with different form-factors, this sample pack helps you determine the perfect tool tracking tag for your application.

Xerafy Pico-On Plus RFID Tag - The Xerafy Pico-On Plus RFID Tag is sized to fit on small metallic assets like blade servers yet exceed competitive read range performance for tags twice its size. At 0.47 x 0.28 x 0.12 inches (12 x 7 x 3 mm) the Pico-On Plus has a small package that packs a mighty punch with up to 10 feet (3 m), providing an unmatched value proposition for multiple markets from IT asset tracking, tool tracking to instrument tracking.

Xerafy Dash-On XS RFID Tag - The Xerafy Dash-On XS RFID Tag is designed to comply with FDA requirements for Unique Device Identification initiative for medical devices. The Dash-On XS is ATEX certified and enables automatic tracking for improved productivity and reduced risks in foreign object debris (FOD), infection control, and product recalls.

Xerafy Slim Trak RFID Tag - The Xerafy Slim Trak is a versatile, low cost, global frequency RFID metal tag that is ideal for asset management requiring a slim profile tag and high performance reads for indoor and outdoor use. Designed with source tagging in mind, the Slim Trak can be integrated into the recess of metal assets without compromising on performance.

What's included?

Why buy this tag?

The Xerafy Tool Tracking Sample Pack is designed with customers in mind who are looking to explore Xerafy tags and RFID tool tracking capabilities within their organization.

We can customize any pack to meet your needs. Contact us for more information.

Features

  • Contains 3 types of Xerafy tags, 2 of each type.
  • UHF RFID tags ideally suited for tool tracking applications.
  • Excellent readability and reliability.
  • Durable, rugged form factor.
  • Equipped with the Alien Higgs-3 integrated circuit.

Product Details

XERAFY PICO-ON RFID TAG

ELECTRICAL

Air Interface Protocol
EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency
FCC (902-928 MHz)
IC Type
Alien Higgs-3
Memory
EPC 96 bits, User 512 bits, TID 64 bits
EPC Memory Content
Unique, randomized number
Max Read Distance
Up to 3 m (10 ft)
Applicable Surface Materials
Metallic surfaces
MECHANICAL

Tag Form Factor
Hard Tag
Tag Materials
Ceramic
Attachment Method
High performance adhesive
Dimensions
12 x 7 x 3.2 mm (0.47 x 0.28 x 0.13 in)
Weight
1.4 g
ENVIRONMENT

Operating Temperature
-30° to +85°C (-22° to +185°F)
XERAFY DASH-ON XS RFID TAG

ELECTRICAL

Air Interface Protocol
EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency
FCC (902-928 MHz)
IC Type
Alien Higgs-3
Memory
EPC 96 bits, User 512 bits, TID 64 bits
EPC Memory Content
Unique, randomized number
Max Read Distance (On-Metal)
Up to 2 m (6.6 ft)
Max Read Distance (Off-Metal)
Up to 1.5 m (5 ft)
Applicable Surface Materials
Metal and non-metallic surfaces
MECHANICAL

Tag Form Factor
Hard Tag
Tag Materials
Ceramic
Attachment Method
Epoxy
Dimensions
12.3 x 3 x 2.2 mm (0.48 x 0.12 x 0.09 in)
Weight
0.44 g
ENVIRONMENT

Operating Temperature
-40° to +85°C (-40° to +185°F)
XERAFY SLIM TRAK RFID TAG

ELECTRICAL

Air Interface Protocol
EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency
Global (860-960 MHz)
IC Type
Alien Higgs-3
Memory
EPC 496 bits, User 128 bits, TID 48 bits
EPC Memory Content
Not guaranteed unique
Max Read Distance
Up to 2 m (6.5 ft)
Applicable Surface Materials
Metal and non-metallic substrates
MECHANICAL

Tag Form Factor
Hard tag
Tag Materials
FR4
Attachment Method
Adhesive, epoxy
Dimensions
56.5 x 5.95 x 1.3 mm (2.22 x 0.234 x 0.05 in)
Weight
1 g
ENVIRONMENT

Operating Temperature
-40° to +85°C (-40° to +185°F)
