Eliminate lost containers and gain real-time visibility as returnable transport items (RTI) move through your supply chain. These RFID labels with advanced AD Dogbone™ M830 Inlay deliver exceptional read ranges up to 21 m (68.9 ft) and reliable performance on challenging materials like plastic, metal, and cardboard that typically interfere with RFID signals. The engineered Dogbone™ antenna shape maximizes sensitivity in demanding warehouse environments, while Gen2X capabilities ensure accurate reads even when containers are tightly stacked or nested inside one another.
Built for the long haul with thermal transfer synthetic facestock and permanent acrylic adhesive, these labels withstand up to five years of exposure to UV light, seawater, and harsh chemicals while keeping printed data clearly legible. Encode labels on demand using any Zebra thermal transfer printer with 5095 resin ribbon for optimal results. Pre-tested through ISO 9001 quality processes with Zebra readers and printers, these labels streamline repetitive workflows like dock door scanning and goods-in capture, freeing your frontline teams to focus on higher-value tasks.
View Data SheetGet expert help selecting the right tag. Check out our tag guide or chat with a specialist.
The AD Dogbone™ M830 Inlay compensates for detuning effects on plastic, metal, and cardboard to deliver consistent reads at distances up to 21 m (68.9 ft), even when containers are stacked or nested. With a permanent adhesive lasting up to five years and resistance to UV, seawater, and chemicals, these labels extend ROI while eliminating the cost of lost or misplaced returnable transport items.
| Product Type: | Tag |
|---|---|
| Air Interface Protocol: | EPCglobal UHF Class 1 Gen 2v2 (ISO/IEC 18000-63) |
| Operating Frequency: | Global (865-928 MHz) |
| IC Type: | Impinj M830 |
| Memory: | EPC 128 Bits, User 0 Bits, TID 96 Bits |
| EPC Memory Content: | Unique, Auto-Serialized |
| Max Read Distance: | 21 m (69 ft) |
| Applicable Surface Materials: | Plastic, Glass, Cardboard, PVC, Fiberglass, Rubber, PTFE |
| Tag Form Factor: | Label Tag |
| Tag Materials: | Topcoated Polyester |
| Recommended Ribbon: | Zebra's 5095 Resin |
| Attachment Method: | Permanent Acrylic Adhesive |
| Dimensions: | 98.6 x 33.3 mm (3.88 x 1.31 in) |
| Weight: | 1.1 g |
| Operating Temperature: | -34°C to 85°C (-30°F to 185°F) |
