Vulcan RFID™

Vulcan RFID™ Iron USB Reader

SKU:
VUL-USB-IRON-1P-ENC
$583.00
ELECTRICAL:

Air Interface Protocol:
EPC UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency:
FCC (917.4 - 927.2 MHZ)
Transmit Power:
Programmable from 0 dBm to 27 dBm in 0.5 dBm steps
Max Receive Sensitivity:
Not published
Max Read Distance:
Testing Recommended
Max Read Rate:
Up to 150 tags/second
Data Interface:
USB
GPIO:
Not published
Power Source:
USB cable (included)
MECHANICAL:

Antenna Ports:
1 SMA Female port: SMA female Flange Right Angle (connects to SMA male)
Dimensions:
85 x 73.5 x 25.2 mm ( 3.35 x 2.89 x 0.99 in)
Weight:
0.028 kg (0.06 lbs)
ENVIRONMENT:

IP Rating:
Not published
Operating Temperature:
-20°C to +50°C (-4°F to +122°F)
APPLICATION INTERFACE:

Host API:
Java, C#, C/C++
Demo Software:
Included
fbt-product:
1987
fbt-product:
1665
fbt-product:
1238
atc-product:
3288
atc-product:
2958
atc-product:
3572
atc-product:
1316

Global Supply Shortages. Order now to receive first available stock.

View full description

Frequently Bought Together

Please choose options for all selected products

  • Choose Options

Description

Vulcan RFID™ Iron USB Reader

The Vulcan RFID™ Iron USB Reader is a small form factor, lightweight, high-performance USB reader. The Iron requires an external controller to be operated and is perfect for IoT applications and other embedded uses where a controller hardware already exists. The metal case provides additional durability and gives this reader a sleek design that can be easily mounted. The Vulcan RFID™ Iron USB Reader is compatible with ThingMagic’s application development tools, including Universal Reader Assistant, which allows rapid creation of solutions to support a wide range of applications. The Iron is also compatible with the Vulcan RFID™ UHF Tag Read & Write Software, which has a user-friendly interface that streamlines the encoding process and is designed to eliminate encoding tags by hand.

Data Sheet  Vulcan RFID™ Iron USB Reader


Need help selecting the right reader? Check out our reader guide.

What's included?

  • Vulcan RFID™ Iron USB Reader Unit
  • Micro USB (Type B) To USB (Type A) Cable

Why buy this reader?

Equipped with a small form factor, the Vulcan RFID™ Iron is a high-performance USB RFID reader ideally suited for access control, android-based systems, loT, and embedded applications.

Features

  • High-performance.
  • Small form factor.
  • Lightweight.
  • Reduces time and cost of developing RFID systems.
  • Common applications: access control, android-based systems, loT, POS (point of sale), Check-In and Check-Out, tag/inlay verification, proof of concept, Tag Commissioning, and embedded applications.
  • Certifiable for operation in countries adopting FCC (NA)

Product Details

ELECTRICAL:

Air Interface Protocol:
EPC UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency:
FCC (917.4 - 927.2 MHZ)
Transmit Power:
Programmable from 0 dBm to 27 dBm in 0.5 dBm steps
Max Receive Sensitivity:
Not published
Max Read Distance:
Testing Recommended
Max Read Rate:
Up to 150 tags/second
Data Interface:
USB
GPIO:
Not published
Power Source:
USB cable (included)
MECHANICAL:

Antenna Ports:
1 SMA Female port: SMA female Flange Right Angle (connects to SMA male)
Dimensions:
85 x 73.5 x 25.2 mm ( 3.35 x 2.89 x 0.99 in)
Weight:
0.028 kg (0.06 lbs)
ENVIRONMENT:

IP Rating:
Not published
Operating Temperature:
-20°C to +50°C (-4°F to +122°F)
APPLICATION INTERFACE:

Host API:
Java, C#, C/C++
Demo Software:
Included
