Description
*This product is reaching end-of-life. Please see ThingMagic IZAR 4-Port UHF RFID Reader by JADAK for a recommended replacement product.
ThingMagic Astra-EX Integrated RFID Reader
Astra-EX is an easy to install, unobtrusive, integrated 2-port reader/antenna designed for office and commercial environments. Driven by ThingMagic's powerful Mercury6e (M6e) UHF RFID Module, Astra EX’s Wi-Fi and Power-over-Ethernet (PoE) options allow for flexible, low cost, single cable installations. Astra-EX blends in well with corporate IT infrastructures and office layouts, and offers full support for ThingMagic’s enterprise-class MercuryAPI software.
Data Sheet — ThingMagic Astra-EX Integrated RFID Reader
Need help selecting the right reader? Check out our reader guide.
What's included?
- Astra-Ex RFID Reader Unit with Integrated Antenna
- Note: Power Supply NOT included.
Why buy this reader?
Driven by ThingMagics powerful Mercury6e (M6e) UHF RFID Module, Astra-EX is an easy to install, unobtrusive, integrated 2-port reader/antenna designed for office and commercial environments. Astra-EX blends in well with corporate IT infrastructures and office layouts, and Power-over-Ethernet (PoE) and Wi-Fi options allow for flexible, low cost, single cable installations.
Features
Key features of Astra-EX reader include
- High performance, EPCglobal Gen2 (optional ISO 18000-6B) support with anti-collision Dense Reader Mode (DRM) and advanced anti-jamming functionality.
- A fully integrated 8.5 dBic circularly-polarized antenna and an RP TNC connector to support an optional secondary external antenna.
- Power over Ethernet (PoE) reduces cabling and electrical outlet proximity requirements.
- Wi-Fi option, providing low cost integration with existing enterprise Wi-Fi networks. Supports enterprise Wi-Fi security standards including TKIP, AES and EAP-TLS.
- 32MB of flash and 64MB of DRAM available for reader-hosted applications.
- LLRP v1.0.1 with multiprotocol extensions.
- A small form factor (10.2”H x 10.2”W x 3”D).
High-performance capabilities and application-specific features include:
- Separate read and write levels, adjustable from 5 dBm to 30 dBm on the integrated antenna and up to 31.5 dBm on the external antenna port.
- A ‘fast search’ mode for reading tags affixed to fast-moving objects.
- Read rate over 750 tags per second with high-performance feature settings.
- Read range up to 30 feet for Generation 2 UHF RFID tags.
- The ability to rapidly adapt to changing tag populations.
- The ability to obtain 128 bytes of data with every tag read.
- Support for the full cool-Log™ command set for IDS SL900A sensor tags
ELECTRICAL: | |
---|---|
Air Interface Protocol: | EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C) |
Operating Frequency: | FCC (902-928 MHz), ETSI (865.6-867.6 MHz), or ACMA (920-926 MHz) depending on selection above |
Transmit Power (external antenna): | Up to 31.5 dBm |
Transmit Power (integrated antenna): | Up to 30 dBm |
Max Receive Sensitivity: | Not Published |
Max Read Distance: | 9+ m (29.6+ ft) |
Max Read Rate: | Over 400 tags/second |
Data Interface: | Ethernet, Wi-Fi |
GPIO: | 4 GPI / 4 GPO plus +5 VDC and ground references |
Power Source (POE): | Power over Ethernet 802.3af in both modes A and B |
Power Source (External DC Power): | 10- 30 VDC supply voltage, max DC power: 15 W |
MECHANICAL: | |
Antenna Ports: | 1 RP-TNC female port (connects to RP-TNC male), Monostatic |
Dimensions: | 259 x 259 x 76 mm (10.2 x 10.2 x 3.0 in) |
Weight: | 2 kg (4.5 lbs) |
ENVIRONMENT: | |
IP Rating: | IP 52 |
Operating Temperature: | -20° to +50°C (-4° to +122°F) |
APPLICATION INTERFACE: | |
Host API: | MercuryAPI and LLRP |
Demo Software: | Universal Reader Assistant (URA) |
