Product Details
*This product must be purchased at the Minimum Order Quantity (MOQ). The MOQ for this product is 100,000 tags. Contact us for details.*
Avery Dennison Smartrac Frog 3D RFID Paper Tag 76 mm | M830
The Avery Dennison Smartrac Frog 3D RFID Paper Tag 76 mm is a high-performance solution engineered for pallet and case-level tracking in supply chain and logistics environments, enabling real-time visibility, optimized pallet usage, and improved inventory management. Its compact True3D design offers complete orientation insensitivity, ensuring consistent read performance even on challenging materials. Powered by the Impinj M830 chip, the Frog 3D delivers excellent read range and reliability across a range of logistics applications. Manufactured with advanced inlay assembly technology and rigorous process monitoring, each tag meets ISO 9001:2015 and ISO 14001:2015 standards for quality and environmental performance.
View Data SheetNeed help selecting the right tag? Check out our tag guide.
Why buy this tag?
The Frog 3D paper tag's compact True3D form factor with full orientation insensitivity enables consistent, high-performance reading on difficult-to-tag materials, making it especially effective for pallet and case-level tracking in dynamic supply chain environments.
Features
- Avery Dennison Smartrac’s inlays and tags are compliant with ISO 9001:2015 Quality Management and ISO 14001:2015 Environmental Management.
- Application areas: industry and supply chain management.
- Integrated circuit: Impinj M830.
- 76.2 x 76.2 mm (3 x 3 in) square footprint.
- True3D design with complete orientation insensitivity.
- Consistent and robust performance on various materials globally.
Product Specs
| Product Type: | Tag |
|---|---|
| Air Interface Protocol: | EPC Class 1 Gen 2 (ISO 18000-6C) |
| Operating Frequency: | Global (860-960 MHz) |
| IC Type: | Impinj M830 |
| Memory: | EPC 128 Bits, User 0 Bits, TID 96 Bits |
| EPC Memory Content: | Unique, Auto-Serialized |
| Max Read Distance: | Up to 22 m (72 ft) |
| Applicable Surface Materials: | Plastic, PTFE, PMMA, PUR, Glass |
| Tag Form Factor: | Paper Tag |
| Tag Materials: | Opaque Matt Paper 79 |
| Recommended Ribbon: | Not Published |
| Attachment Method: | Permanent Adhesive |
| Dimensions: | 76.2 x 76.2 mm (3.00 x 3.00 in) |
| Weight: | 1 g |
| Operating Temperature: | -40° to +85°C (-40° to +185°F) |
