Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

SKU:
3004837

Avery Dennison

UPC:
Product Type:
Tag
ELECTRICAL:

Air Interface Protocol:
EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency:
FCC band (860 - 960 MHz), ETSI band (860 - 960 MHz)
IC Type:
RFMicron Magnus S
Memory:
EPC 128 bits, User 144 bits, TID 64 bits
EPC Memory Content:
Not Guaranteed
Max Read Distance:
Not Published
Applicable Surface Materials:
Cardboard, plastic, stone, wood, and other non-metallic materials
MECHANICAL:

Tag Form Factor:
Wet inlay
Tag Materials:
Printable clear PET (Thermal Transfer)
Attachment Method:
Adhesive
Dimensions:
97 x 27 mm (3.8 x 1.06 in)
Weight:
<1 g
ENVIRONMENT:

Operating Temperature:
-40° to +85° C (-40° to +185° F)

Visit Avery Dennison Smartrac DogBone RFID Wet Inlay | M750 for an alternative.

View Full Description View Items Frequently Bought Together

Contact Us for Availability

Need a Quote?

Frequently Bought Together

Please choose options for all selected products

Specs

Description

*Subject to availability. Visit Avery Dennison Smartrac DogBone RFID Wet Inlay | M730 for an alternative product.

What is a Catalog Product?

Catalog Only Products are high-quality RFID tags that have either yet to be released, are not commonly stocked, or are legacy offerings that are reaching end-of-life (EOL). Pricing, lead time, and minimum order quantity (MOQ) on all catalog-only pages is representative only and subject to change. Please contact us to confirm availability and receive a quote.

NOTE: Due to only being purchased to order, all Catalog Only products are final sale and may not be returned or exchanged.

Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

Avery Dennison Smartrac’s state-of-the-art SENSOR DOGBONE brings new features to the company’s inlay and tag product range. It is specially designed to measure moisture conditions in industrial environments, e.g. in construction, energy, healthcare, automotive production and the military.

The Avery Dennison Smartrac Sensor DogBone is a passive UHF inlay equipped with RFMicron’s Magnus®S IC. This RFID sensor inlay offers great performance, and accurately detects and measures moisture levels in the surrounding environment. The sensing information is digitized and wirelessly communicated to off-the-shelf readers using a standard UHF Gen 2 protocol READ command for further processing.

US Data Sheet  Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

US Data Sheet — Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

EU Data Sheet  Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

EU Data Sheet — Avery Dennison Smartrac Sensor DogBone RFID Wet Inlay | RFMicron Magnus S

Need help selecting the right tag? Check out our tag guide.

Why buy this tag?

The Avery Dennison Smartrac Sensor DogBone is a passive RFID tag that can accurately detect and measure moisture levels in the surrounding environment.

Features

  • Application areas include healthcare, construction, and automotive.
  • Low cost and great performance.
  • Works on low- and high-dielectric materials.

Video

Product Type: Tag
ELECTRICAL:
Air Interface Protocol: EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C)
Operating Frequency: FCC band (860 - 960 MHz), ETSI band (860 - 960 MHz)
IC Type: RFMicron Magnus S
Memory: EPC 128 bits, User 144 bits, TID 64 bits
EPC Memory Content: Not Guaranteed
Max Read Distance: Not Published
Applicable Surface Materials: Cardboard, plastic, stone, wood, and other non-metallic materials
MECHANICAL:
Tag Form Factor: Wet inlay
Tag Materials: Printable clear PET (Thermal Transfer)
Attachment Method: Adhesive
Dimensions: 97 x 27 mm (3.8 x 1.06 in)
Weight: <1 g
ENVIRONMENT:
Operating Temperature: -40° to +85° C (-40° to +185° F)
