Distribute and monitor critical power in your IT or industrial environment with the Eaton Tripp Lite PDUMNV30HVLX 5.5kW Monitored PDU. Gain real-time visibility into voltage, frequency, and load levels via its built-in network interface, preempting overloads that lead to costly downtime. Power up to 24 devices with 20 C13 and 4 C19 outlets, securely held in place by included cord retention brackets, ensuring consistent power delivery for your essential equipment.
Maintain complete control over your power infrastructure from anywhere with the pre-installed, secure HTML5-based LX Platform interface, eliminating the need for Java. You can effortlessly manage and monitor PDU status, receive email notifications, and view real-time load levels on the digital ammeter. Maximize your rack space with its 0U vertical rack-mount design and benefit from TAA compliance, making the PDUMNV30HVLX an excellent and reliable choice for government and industrial applications.
View Data SheetThe Eaton Tripp Lite PDUMNV30HVLX 5.5kW Monitored PDU offers a robust power solution, delivering real-time remote monitoring of voltage, frequency, and load levels through its advanced LX Platform network interface. With 20 C13 and 4 C19 outlets, a 3.05 m (10 ft) NEMA L6-30P input cord, and flexible 0U vertical rack-mount options, this PDU ensures efficient power distribution and helps prevent costly downtime by allowing you to easily track and manage your power consumption.
| Product Type: | Computing Device Accessory |
|---|---|
| PDU Type: | Monitored |
| Input Voltage: | 208/230V Single-Phase |
| Input Plug: | NEMA L6-30P |
| Input Cord Length: | 3.05 m (10 ft) |
| Maximum Input Current: | 24A continuous |
| Output Capacity: | 5.5kW (230V) / 5kW (208V), 24A continuous |
| Output Receptacles: | (20) C13, (4) C19 with cord retention brackets |
| Overload Protection: | Two 20A breakers, 12 outlets each |
| Frequency Compatibility: | 50/60 Hz |
| Current Measurement Accuracy: | +/-2% |
| Network Interface: | Pre-installed WEBCARDLX, LX Platform (PADM20), Java-free HTML5 |
| Network Speed: | 10/100 Mbps (Fast Ethernet) |
| Protocols Supported: | HTTP, HTTPS, SMTP, SNMPv1/v2/v3, Telnet, SSH, FTP, DHCP, NTP |
| Mounting: | 0U Vertical Rack-Mount, toolless buttons or included brackets |
| Dimensions: | 177.8 x 5.6 x 6.7 cm (70.0 x 2.19 x 2.65 in) |
| Weight: | 5.22 kg (11.5 lbs) |
| Operating Temperature: | 0° to 40°C (32° to 104°F) |
| Storage Temperature: | -30° to 60°C (-22° to 140°F) |
| Relative Humidity: | 5% to 95% non-condensing |
| Operating Elevation: | 0–3000 m (0–10,000 ft) |
