Description
*Formerly sold under the name "Confidex Silverline Blade™ RFID Tag". This is the same great tag - just with a new name. This product is end-of-life. Visit Zebra Silverline Blade II™ RFID Tag by Confidex (M730) for a recommended replacement product*.
Zebra Silverline Blade™ RFID Tag by Confidex
With footprint of only 2.5 x 6 cm and thickness of 1.2 mm, the Zebra Silverline Blade™ RFID Tag by Confidex is small and unobtrusive passive RFID label. Despite the small size, the Blade boasts a respectable 4.5 meter read range on metal. Equipped with an innovative antenna design, the Silverline Blade™ handles the complete global RFID radio frequency range of 865 to 928 MHz – without harming the performance. The Silverline Blade™ is easy to print and program on-demand making it an ideal solution for tagging your assets from servers to refrigerators.
Data Sheet — Zebra Silverline Blade™ RFID Tag by Confidex
Need help selecting the right tag? Check out our tag guide.
Why buy this tag?
Equipped with a small form factor, global frequency range, and long read distance, the Zebra Silverline Blade™ RFID Tag by Confidex is a printable on-metal label optimized for asset tagging.
Features
- IP 68 rated.
- Optimized for asset tagging.
- Printable, metal-mount label tag.
- Can be applied on a curved surface.
- Tolerates industrial washing with standard solvents.
- Worldwide operation in the RFID UHF bands (865-928 MHz).
Printer Compatibility
- Custom Zebra ZT410 RFID Silverline Printer
- Other Zebra printers are not recommended or supported
- Zebra 5095 Resin Ribbon recommended
Video
| Product Type: | Tag |
|---|---|
| ELECTRICAL: | |
| Air Interface Protocol: | EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C) |
| Operating Frequency: | Global (865-928 MHz) |
| IC Type: | Impinj Monza R6 |
| Memory: | EPC 96 bits, TID 48 bits |
| EPC Memory Content: | Unique number encoded as a default |
| Max Read Distance - On Metal: | Up to 4.5 m (15 ft) |
| Max Read Distance - On Plastic: | Up to 1.5 m (5 ft) |
| Max Read Distance - On Liquid Containers: | Up to 3 m (10 ft) |
| Applicable Surface Materials: | All surfaces, optimized for metal |
| MECHANICAL: | |
| Tag Form Factor: | Hard label tag |
| Tag Materials: | White specially coated PP |
| Recommended Ribbon: | Full resin |
| Recommended Printer: | Zebra ZT410 Silverline |
| Attachment Method: | High tack adhesive |
| Dimensions: | 60 x 25 x 1.2 mm (2.36 x 0.98 x 0.047 in) |
| Weight: | 0.6 g |
| ENVIRONMENT: | |
| Operating Temperature: | -35° to +85°C (-31° to +185°F) |
| fbt-product: | 2370 |
| fbt-product: | 3572 |
| fbt-product: | 1665 |
| atc-product: | 2963 |
| atc-product: | 3596 |
| atc-product: | 3505 |
| atc-product: | 2958 |
| Short Description: | Product is end-of-life. Visit Zebra Silverline Blade II™ RFID Tag by Confidex (M730) for an alternative product. |
