Eaton Tripp Lite PDUMH15AT 1.4kW ATS PDU | 8 NEMA 5-15R Outputs | 1U Rack-Mount

Ensure uninterrupted power for your vital network equipment with the Eaton Tripp Lite PDUMH15AT 1.4kW ATS PDU, offering a seamless automatic transfer switch (ATS) solution to prevent costly downtime. This 1U rack-mount single-phase PDU provides a redundant A/B power option for devices with a single power input, intelligently switching between primary and secondary power sources supplied by its dual 12 ft. (3.6m) NEMA 5-15P input cables. Experience virtually instantaneous switchover between power sources in just 2-7 milliseconds, keeping your operations online and efficient, even during power fluctuations or outages.

Monitor your power consumption at a glance with the built-in digital current meter, constantly displaying the total output load in amps. With 8 NEMA 5-15R outputs, this local metered PDU is designed for reliable performance, offering 1.44kW (120V) of total capacity. Tailored for federal procurement, it is TAA compliant for GSA schedule purchases and can be enhanced with an optional SNMPWEBCARD or WEBCARDLX for remote management capabilities, making it an essential component for critical infrastructure where continuous power delivery is paramount.

• ATS / Local Metered PDU with attached 5-15P primary input cord
• Detachable C13 to NEMA 5-15P 12 ft / 3.6m secondary input cord
• 1U rackmount installation brackets
• User manual
• 2-year limited warranty

Ensure uninterrupted power for your vital network equipment with the Eaton Tripp Lite PDUMH15AT, featuring a super-fast 2-7 millisecond automatic transfer switch that seamlessly transitions between primary and secondary power sources. This 1U rack-mount solution provides a redundant A/B power option for single-corded devices, protecting against unexpected outages and offering critical fault-tolerant UPS protection in a compact 4.44 x 44.4 x 36.8 cm (1.750 x 17.500 x 14.500 in) form factor with 8 NEMA 5-15R outlets and real-time current metering.

• Capacity and Outputs: 1.4kW Single-Phase Local Metered ATS PDU with 8 NEMA 5-15R outputs
• Automatic Transfer Switching (ATS): Provides redundant power from primary or secondary sources, switching within 2 to 7 milliseconds if the primary fails or becomes unstable
• Dual Input Power: Features two 3.6 m (12 ft) NEMA 5-15P input cables for connection to separate primary and secondary power sources
• Power Quality Monitoring: On-board ATS processor continuously evaluates power quality from both inputs to prevent transfer to an unstable secondary source
• Digital Current Meter: Front panel two-digit display continuously reports total output power consumption in amps
• Compact Rack-Mount Design: Space-saving 1U horizontal rackmount form factor with a 36.8 cm (14.5 in) depth
• Expandable Monitoring: Includes a built-in slot for optional SNMPWEBCARD or WEBCARDLX for remote monitoring and control
• Sequential Outlet Turn-On: Factory-programmed sequential turn-on of outlets at 250-millisecond intervals to prevent inrush current issues during startup
• TAA Compliant: Federal Trade Agreements Act (TAA) compliant for GSA schedule purchases
• Visual Status Indicators: Front panel LEDs clearly display primary and secondary input power availability, as well as the on/off status for each outlet
• Ideal For: Providing redundant power to single-corded network devices, advanced redundant power networking applications, and fault-tolerant hot-swappable UPS protection
